Microprocessor-Controlled Traction Home Elevator – Quiet, Safe, Customizable
Product Details:
| Place of Origin: | China |
| Brand Name: | YIMEISITE |
| Certification: | ISO 9001 ISO 14001 UDEM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD 10,000-20,000 per set |
| Packaging Details: | Export non-fumigation wood box |
| Delivery Time: | 45 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Safety Features: | Emergency Stop Button, Overload Protection, Safety Sensors | Type: | Home Elevator |
|---|---|---|---|
| Power Supply: | 220V/380V, 50Hz/60Hz | Control System: | Microprocessor-based Control System |
| Operating Temperature: | 0-40°C | Door System: | Automatic Sliding Doors |
| Capacity: | 400-1000 Kg | Warranty: | 1 Year |
| Highlight: | Microprocessor Based Control Traction Elevator,1000Kg Electric Traction Lift,400Kg Electric Traction Lift |
||
Product Description
Why Choose This Lift
- Gearless VVVF traction delivers a smooth 0.6 m/s ride with low energy draw
- Safety suite includes emergency stop button, overload guard and infrared door sensors
- Automatic sliding doors with aluminium or steel well-shaft options for fast retrofit
- Capacities from 400 kg to 1000 kg serve villas, duplexes and penthouses
- ISO 9001, CE and EAC certified and backed by a one-year warranty
At-a-Glance Specs
| Feature | Detail |
|---|---|
| Drive system | Gearless traction |
| Load capacity | 400 / 630 / 800 / 1000 kg |
| Max travel height | 30 m (≈ 8–10 stops) |
| Speed | 0.6 m/s (VVVF) |
| Noise level | ≤ 60 dB |
| Doors | Automatic sliding (centre / side) |
| Control | Microprocessor |
| Power supply | 220 V / 380 V, 50/60 Hz |
| Operating temp | 0–40 °C |
| Safety | E-stop, overload, safety sensors |
| Warranty | 12 months |
Ideal Installations
- Compact residential elevators across Vietnam, Malaysia, Philippines, Indonesia, Australia, Mexico, UAE, Myanmar, Singapore, Saudi Arabia, Egypt, Sudan, Thailand, Colombia, Israel, Qatar, Taiwan, Kazakhstan and Uzbekistan
- Retrofit elevator projects where pit depth and headroom are limited
- Glass residential elevators adding value to luxury homes and boutique hotels
Request Your Quote
Send your floor plan to receive a detailed lift-elevator price including equipment, delivery and installation within 48 hours.
