Noise-Reduced Gearless Traction Elevator for Villas & Multi-Storey Homes
Product Details:
| Place of Origin: | China |
| Brand Name: | YIMEISITE |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD 10,000-20,000 per set |
| Packaging Details: | Export non-fumigation wood box |
| Delivery Time: | 45 working days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Travel Height: | Up To 30 M | Type: | Home Elevator |
|---|---|---|---|
| Door System: | Automatic Sliding Doors | Drive System: | Gearless Traction |
| Warranty: | 1 Year | Speed: | 0.6 M/s |
| Capacity: | 400-1000 Kg | Noise Level: | Less Than 60 DB |
| Highlight: | gearless home elevator,sliding doors home elevator,sliding doors gearless traction elevator |
||
Product Description
Why This Lift Stands Out
- Gearless VVVF drive delivers whisper-quiet rides under 60 dB
- Microprocessor control with emergency stop, overload and light-curtain sensors
- Automatic sliding doors in glass, stainless steel or wood veneer; side or through entrances
- Supports up to 30 m travel height and 0.6 m/s speed; capacities from 400 kg to 1000 kg
- Steel or aluminium self-supporting shaft allows fast retrofit installation with no machine room
- ISO 9001, CE and EAC certified; backed by a 1-year warranty and local service teams
Key Specifications
| Spec | Detail |
|---|---|
| Capacity | 400 / 630 / 800 / 1000 kg |
| Max rise | 30 m (≈ 8–10 stops) |
| Speed | 0.6 m/s (VVVF) |
| Drive | Gearless traction |
| Door | Automatic centre / side slide |
| Power | 220 V or 380 V, 50/60 Hz |
| Noise | < 60 dB |
| Operating temperature | 0 – 40 °C |
| Safety | E-stop, overload, IR sensors |
| Warranty | 12 months |
Typical Applications
- Luxury villas and duplexes in Vietnam, Malaysia, Indonesia, Australia, Mexico, UAE, Myanmar and Singapore
- Retrofit residential elevator projects where pit depth is limited
- Boutique hotels, clinics and offices needing a quiet, energy-efficient lift
Request Your Quote
Send your floor plan and preferred finishes to receive a detailed home-lift price including equipment, delivery and installation within 48 hours
